SUPER POWERFUL AND DYNAMIC BOSCH PERFORMANCE LINE CX E-DRIVE
Thanks to the efficient Bosch Performance Line CX system, you can ride more trails in the same time. The powerful e-drive with a torque of up to 85 Nm makes sure uphill with the JAM² 6.8 is fun as well. Even though the motor has got your back on climbs, you can still easily control your full-suspension bike, also in toughest conditions. The slide-out battery with 750 Wh can be charged via the integrated charging port at the bike’s seat tube. Alternatively, you can also remove the battery easily and fast. There is no need for any tools. Just unlock the buckle and open the cover to slide out the battery.
GEOMETRY FOR MAXIMUM FUN ON ALL TYPES OF TRAILS
Battery and drive unit are perfectly integrated into the e-MTB's frame giving the JAM² 6.8 a slim look. Further, the battery is placed as low as possible into the down tube. This frame design improves the bike's centre of gravity and makes the full suspension bike more stable on descents. The balanced geometry adds up to the e-MTB's stability. All key dimensions are evaluated carefully to match the bike’s purpose and ensure fun on all trails. The low stand-over height improves bike handling in technical terrain. By turning the headset cups, you can easily change the head angle of your JAM² 6.8 according to your riding preferences from 65.5° to 64.5°.
FULL CONTROL IN ANY SITUATION
When optimising the F.O.L.D. (FOCUS Optimised Linkage Design) of our JAM² 6.7, it was extremely important to create a reactive kinematics and suspension for full control – whether it’s a technical or flow trail, no matter if you go up or down. Wide and tacky 29" tyres improve traction on every surface, while you can always rely on strong brakes. Thanks to great brake modulation, you can reduce your speed precisely and with high confidence.
KEY FEATURES
DRIVE UNIT Bosch Performance CX Smart, 85 Nm, 250 W
BATTERY Bosch Powertube 750 Wh
DISPLAY Bosch LED Remote + Kiox 300
SPECIFICATIONS
- FRAME MATERIAL
Aluminium - FRAME
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematics, 148x12 mm thru axle, internal cable routing, post mount 203 mm - FORK
FOX 36 Float Rhythm 29 E-Bike, Grip, 110 x 15 mm, 44 mm rake - TRAVEL OF SUSPENSION FORK
160 mm - SHOCK
FOX Float DPS, 210 / 55 mm, hardware: 25.0 x 8.0 mm, no Bushing - SHIFTER
Shimano Deore XT SL-M8100, 12-speed - REAR DERAILLEUR
Shimano Deore XT SL-M8100, 12-speedd - SPROCKET
Shimano Deore CS-M6100, 12-speed - CHAIN
Shimano Deore CN-M6100, 12-speed - CRANKSET
Samox EC40 ISIS - TRANSMISSION OF DRIVE
front: 36, rear: 10-51 - BOTTOM BRACKET
Integrated in Drive Unit
- HANDLEBAR
Aluminium, 800 mm, rise: 30 mm, backsweep: 9° - STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium - HEADSET
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset - SADDLE
Selle Italia X3 - SEATPOST
Post Moderne dropper post PM-214, 34.9 mm - BRAKE CALIPER
SRAM DB8, 4-piston, hydraulic disc brake - BRAKE LEVER
SRAM DB8, 4-piston, hydraulic disc brake - BRAKE
Disc - RIMS
RaceFace AR30 Offset - REAR HUB
Novatec D462, 12x148 mm - FRONT HUB
Novatec D041, 15x110 mm - TYRES
Maxxis Minion DHR II, 2.6, 66-622, EXO+ - GEARS
12 - BIKE WEIGHT INCL. BATTERY IN KG.
25,5 - SIZE
39,42,44,46
* Subject to technical modification without notice. Errors and omissions excepted.
- High Position
- Low Position
