SUPER POWERFUL AND DYNAMIC BOSCH PERFORMANCE LINE CX E-DRIVE
hanks to the efficient Bosch Performance Line CX system, you can ride more trails in the same time. The powerful e-drive with a torque of up to 85 Nm makes sure uphill with the JAM² 6.7 is fun as well. Even though the motor has got your back on climbs, you can still easily control your full-suspension bike, also in toughest conditions. The slide-out battery with 625 Wh can be charged via the integrated charging port at the bike’s seat tube. Alternatively, you can also remove the battery easily and fast. There is no need for any tools. Just unlock the buckle and open the cover to slide out the battery.
GEOMETRY FOR MAXIMUM FUN ON ALL TYPES OF TRAILS
Battery and drive unit are perfectly integrated into the e-MTB's frame giving the JAM² 6.7 a slim look. Further, the battery is placed as low as possible into the down tube. This frame design improves the bike's centre of gravity and makes the full suspension bike more stable on descents. The balanced geometry adds up to the e-MTB's stability. All key dimensions are evaluated carefully to match the bike’s purpose and ensure fun on all trails. The low stand-over height improves bike handling in technical terrain. By turning the headset cups, you can easily change the head angle of your JAM² 6.7 according to your riding preferences from 65.5° to 64.5°.
FULL CONTROL IN ANY SITUATION
When optimising the F.O.L.D. (FOCUS Optimised Linkage Design) of our JAM² 6.7, it was extremely important to create a reactive kinematics and suspension for full control – whether it’s a technical or flow trail, no matter if you go up or down. Wide and tacky 29" tyres improve traction on every surface, while you can always rely on strong brakes. Thanks to great brake modulation, you can reduce your speed precisely and with high confidence.
KEY FEATURES
DRIVE UNIT Bosch Performance CX Smart, 85 Nm, 250 W
BATTERY Bosch Powertube 625 Wh
DISPLAY Bosch LED Remote
SPECIFICATIONS
- FRAME
- 7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. kinematics
- FORK
Rockshox Recon Silver RL, 160mm. 44 mm rake - SHOCK
RockShox Deluxe Select, 210/55 mm, Hardware: 25.0 x 8.0 mm - SHIFTER
Shimano Deore M6100, 12-speed - REAR DERAILLEUR
Shimano Deore RD-M6100, 12-speed - CASSETTE
Shimano Deore CS-M6100, 12-speed - CHAIN
Shimano Deore CN-M6100, 12-speed - CRANKSET
Samox EC40 ISIS - TRANSMISSION OF DRIVE
front: 36, rear: 10-51 - BOSCH POWERMORE COMPATIBLE
Please contact us
- HANDLEBAR
Aluminium, 800 mm, rise: 30 mm, backsweep: 9° - STEM
FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium - HEADSET
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset - SADDLE
Selle Royal Groove - SEATPOST
Post Moderne dropper post PM-214, 34.9 mm - BRAKES
Shimano MT520, 4-piston - RIMS
RODI TRYP30, 30-622 - HUBS
Rear: Novatec D462SB, 12x148 mm. Front: Novatec D041, 15x110 mm - TIRES
Maxxis Minion DHF 29x2.6", EXO, 63-622 - BIKE WEIGHT INCL. BATTERY IN KG.
25 - SIZE
S,M,L,XL
* Subject to technical modification without notice. Errors and omissions excepted.
