Product details

Description

Retaining its signature top tube frame and available in three sizes, the Bighorn boasts the same sleek downtube which houses a large 720Wh capacity battery, featuring the latest Samsung 21700 cells for extended power and endurance.

Now, with the groundbreaking addition of smart technology, the Bighorn offers unparalleled connectivity through its integrated SIM module, running on the 4G network. Paired with the new Wattwheels app, users can access a range of features including bike diagnostics, theft reporting, and real-time tracking, with more innovations on the horizon.

  • Real-time GPS Location: With a 4G SIM card, track your bike's whereabouts anytime, anywhere.
  • Geo-fencing: Receive instant alerts if your bike is moved outside designated boundaries.
  • Report Stolen Bike: In the unfortunate event of theft, report your bike stolen directly through the app, triggering security measures and shutting down the bike.
  • Dealer Locator: Easily locate and connect with authorized Wattwheels dealers for support and service.
  • Remote Bike Control: Take command of your eBike's features remotely—toggle lights, and adjust PAS, all at your fingertips.
  • Remote Diagnosis: Diagnose and troubleshoot any issues seamlessly through the app, ensuring your ride is always in peak condition.

The app is included for the first year in the price of the bike but after that, it must be renewed yearly at a cost of $59.95 per year. Of course, if you don't want to use the app and just want to ride the bike you don't need to renew the app

THE APP WILL BE LIVE TO DOWNLOAD FROM THE GOOGLE PLAY/APPLE STORE FROM SEPT 1ST 2024. FOR INSTRUCTIONS AROUND THIS KEEP AN EYE ON OUR YOUTUBE CHANNEL AND WAIT FOR THE VIDEO TO BE UPLOADED - WATTWHEELS YOUTUBE

(Note - You can not upgrade to the app software with older bighorn models, unfortunately)

Powered by the renowned Ananda M100 motor, delivering whisper-quiet operation and an impressive 120N.m of torque, conquering the steepest climbs is effortless. Coupled with the dependable 10-speed Shimano Deore drivetrain and Shimano hydraulic brakes, the Bighorn ensures a confident and smooth ride from start to finish.

Complete with essential accessories including mudguards, rear rack, front and rear lights, and now featuring color displays with integrated USB ports for convenient device charging, the Bighorn offers unparalleled versatility and functionality.

Another addition to the 24 models is the option to add a front rack for extra storage +$99RRP

Whether tackling iconic New Zealand trails or navigating city streets, the Bighorn stands as the ultimate universal bike, offering both performance and practicality for every journey.

E-bike Specific
  • DRIVE UNIT
    Ananda M100 300Watt Motor(120N.m Torque) - Canbus system
  • BATTERY
    48V15Ah 21700 Samsung Li-Ion Cells 5000Mah (720WH) Smart BMS
  • THROTTLE
    Thumb Left hand (can be removed)
  • SMART BIKE
    Yes - Has an inbuilt sim module that can be paired with the Wattwheels App.
  • CHARGER
    Sans 48V3Ah Smart Charger
  • SPEED
    Up to 45km/h
Technical Info

FRAMESET

  • FRAME
    Med (27.5" wheels) and Large and Extra LArge (29" wheels) in Low Step frames. (option to purchase front rack +$99)
  • FORK
    Suntour XCM34 E-Bike rated with Boost & Lockout - 100mm Travel

DRIVETRAIN

  • SHIFTER
    Shimano Deore 10sp M5130
  • REAR DERAILLEUR
    Shimano Deore 10 Speed Linkglide
  • CASSETTE
    Shimano 11-43 LG400
  • CRANKSET
    Ananda Isis 44T, 170mm
  • CHAIN
    Shimano LG500
  • HANGER
    Sram UDH


BRAKES

  • BRAKES
    Tektro Hydraulic 180mm Rotors
  • BRAKE ROTORS
    180 mm rear

WHEELS

  • RIMS
    Alexrims DP30 27.5/29 13G*36H
  • HUBS
    Sealed Bearing
  • TYRES
    Maxxis Ikon 27.5 *2.25 - (29 on L& XL 19inch model)

COMPONENTS

  • GRIPS
    Velo 140mm Lock On
  • HANDLEBAR
    Promax 680mm, 31.8, 10mm Rise (Sweep on Low step frames)
  • SADDLE
    Foam Velo  - Black
  • SEATPOST
    31.60 Alloy

OTHERS

  • LIGHTS
    Integrated front and rear
  • RACKS
    Rear rack included with Mudguards
    Options to add front rack for extra storage at $99
  • SIZES
    Medium, Large and Extra Large
  • COLOUR
    Misty Blue, Moroccan Red or Deep Sea Blue
  • WEIGHT
    24kg (battery + 3.75kg)
  • WARRANTY
    Full Comprehensive - 5 years frame, 2 years motor/battery/display and 12months on mechanical components
  • WEIGHT LIMIT
    This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 130 kg

  • Ananda M100 300Watt Motor(120N.m Torque)

  • Samsung Li-Ion Cells 5000Mah (720WH) Smart BMS

  • Suntour XCM34 - 100mm

  • Tektro Hydraulic 180mm Rotors

  • 27,5"

Contact Us

Complete the contact form below if you are interested in this E-bike or if you would like more information.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

FAQs

Why can I not order this bike through the webshop?

We aim to provide you with the best service in finding the right E-bike. As a result, we don't directly sell our bikes from our online store. However, we do provide delivery of E-bikes nationwide. Please contact our team using the form above to get in touch, +64 7 460 0844.

Can I test-ride this E-bike?

Feel free to visit our shop at 1280 Fenton Street, Rotorua and take the bike for a test ride around the block. Please remember to bring some photo ID, as it is required before taking the bike out. The test ride should be limited to the town area and should not include off-road or forest riding. Check with our team before your visit to see if the bike is in stock and available for test riding.

What is the battery range on this E-bike?

Determining the exact range of your E-bike is not straightforward, as it depends on various factors such as the total load, the terrain, temperature, battery size, and motor unit. Some motor brands provide a range indication or provide a tool, like the Bosch Range Calculator.

--> Please reach out to the EBR team, and we can provide you with a good estimate by asking a few simple questions, +64 7 460 0844.

Are there any services included in the bike sale?

We offer an in-house complimentary first check for all bikes purchased at Electric Bike Rotorua. The first check is done at 6 weeks (after the bike purchase) or 250km, whichever comes first.
