FEATURES

• Updated version of DU-EP800 with expanded system connectivity delivers evolved e-MTB performance and even greater value
• Expanded system capabilities with CAN and ACC ports
• Natural and refined assist delivery from a light, quiet, and more compact motor with less pedaling drag
• New customization options and Finetune Mode with E-TUBE PROJECT
• Maximum torque: 85 Nm
• Lightweight magnesium body: 2.7 kg
• Only compatible with second-generation battery management system (BMS)
• Delivers more consistent climbing speed and better-than-ever acceleration at higher cadences, which is excellent for pedaling out of corners.
• Maximum power output: 600 W



Model No

DU-EP801

Series

EP8

Battery management system

Second generation

Motor type

Brushless motor

Position

Mid-drive

Compatible wheel size (mm)

*1300-3000

Continuous rated power (Watt)

250

Maximum torque (Nm)

85

Rated voltage

36 V DC

Di2 compatible:

Internal geared hub

✔

Rear derailleur

✔

Maximum support bike speed:

45km/h

Finetune mode

✔

Assist customize

Number of profile

2

Assist mode

BOOST

✔

HIGH

✔

TRAIL

✔

NORMAL

✔

ECO

✔

Power supply for front light

12 V DC

Power supply for rear light

12 V DC

Maximum current supply front and rear light total (A)

2

Power supply and maximum current for ACC

13.5 V DC / 2.0 A

Power supply and maximum current for CAN port

12 V DC / 2.0 A

Safe way home function

✔

Communication

E-TUBE

Master unit

✔

Firmware update by E-TUBE PROJECT

✔

SD50 port (pcs)

0

SD300 port (pcs)

3

SD50 connector (pcs)

0

SD300 connector (pcs)

0

Terminal for light (pcs)

1

Port for electric devices (pcs)

2

Port for Speed Sensor (pcs)

SD50 type

0

SD300 type

1

Chain case compatible

✔

Chain device compatible

✔

Torque sensor

✔

Crank arm position sensor

✔

Bike speed sensor

✔

Cadence sensor

✔

Walk assist function

On/Off

✔

Automatic shift:

Internal geared hub 8-speed

✔

Internal geared hub 5-speed (INTER-5E)

✔

Rear derailleur

✔

SYMPHOMATIC

Internal geared hub

✔

Rear derailleur

✔

Electronic shift by drive unit control

✔

Compatible spindle type

24mm narrow

Drive unit fixing screw (pcs)

6

Average weight

2.7
