A CLASS APART, A LANE AHEAD
The Vintage Electric Cafe is the commuter electric bike rebooted. This wolf in sheep’s clothing is our equivalent of a 500HP V8…hidden under the hood of the family sedan. With 3X the power of its competitors the Cafe walks quietly, but carries a big stick. Wedged within the mild-mannered-styling of the pedal assist commuter, is a ferocious power plant, producing a surreal level of speed and acceleration. All the benefits of bicycle commuting have been amplified by the electric drive train and vintage-inspired aesthetics, putting the Cafe electric bike in a lane of its own.
ACCESSORIES
Premium Flick Bell, Greenfield Center Mount Kickstand, Aluminum Alloy Paint-Matched Fenders, Aluminum Alloy Paint-Matched Chain Cover, Integrated Supernova E3 E-Bike V6S Headlight (165 Lumens), Integrated Supernova E3 Rear Light
KEY FEATURES
FRAME TYPES: High- Step
FRAME COLORS: Skyline Bronze, Golden Gate Red
FRAME SIZES:17.5 in (44.45 cm)18.5 in (46.99 cm)19.5 in (49.53 cm)
GEOMETRY MEASUREMENTS:Medium 18.5 Measurements: 18.75" Seat Tube, 22.5" Reach, 31.5" Stand Over Height, 28" Width, 72" Length, Small 17.5 Measurements: 17.75" Seat Tube, 31" Stand Over Height
SPECIFICATIONS
- FRAME FORK DETAILS
Rigid Aluminum Alloy, 100 mm Hub Length, 15 mm Maxle with Quick Release - FRAME REAR DETAILS
135 mm Hub, 12 mm Axle with Nuts - ATTACHMENT POINTS
Rear Rack Bosses, Fender Bosses - GEARING DETAILS
10 Speed 1x10 Shimano Deore XT Derailleur with Shadow Plus Clutch, 11-34T Cassette - SHIFTER DETAILS
Shimano SLX Two-Way Triggers on Right - CRANKS
FSA CK-633 F. Gimondi, Aluminum Alloy, 170 mm Length, F. Gimondi 44 Tooth Chainring. - PEDALS
MKS, Aluminum Alloy Platform, Silver - HEADSET
Tapered 1-1/8" to 1-1/2" Sealed Cartridge - STEM
Promax, Aluminum Alloy, 70 mm Length, 7° Angle, 31.8" Clamp Diameter - HANDLEBAR
Low-Rise, Aluminum Alloy, 700 mm Length - BRAKE DETAILS
Shimano Hydraulic Disc with 180 mm Front Rotor, 160 mm Rear Rotor, Three-Finger Shimano Levers with Adjustable Reach - GRIPS
Velo, Stitched Leather with Lockers - SADDLE
Velo, Leather, Perforated Dual Density with Integrated Supernova LED Light - SEAT POST
Aluminum Alloy, length: 350 mm, diameter 27.2mm - RIMS
Aluminum Alloy, Double Wall, Color Matched, 36 Hole - SPOKES
Stainless Steel, Hand Laced and Tensioned, 14 Gauge Front, 13 Gauge Rear, Adjustable Nipples, Silver - TIRE BRAND
Schwalbe Fat Frank, 28" x 2.0"
- WHEEL SIZES
28 in (71.12cm) - TIRE DETAILS
30 to 65 PSI, Reflective Sidewall Stripe, Available in Black or Creme Colors, Active Line K-Guard Puncture Protection - TUBE DETAILS
Presta Valve - MOTOR BRAND
Custom TDCM - MOTOR TYPE
Rear-Mounted Gearless Direct Drive Hub - MOTOR NOMINAL OUTPUT
750 watts - MOTOR TORQUE
70 Newton meters - BATTERY VOLTAGE
48 volts (35 Amps Continuous) - BATTERY HOURS
10.4 ah / 499.2 wh - BATTERY CHEMISTRY
Lithium-ion - CHARGE TIME
2 hours - ESTIMATED RANGE
Max. 97 km - DISPLAY TYPE
Fixed, Monochrome, Backlit, LCD Display, (Hold Up for Lights, Hold Down for Walk Mode, Hold Up and Down for Settings) - READOUTS
Battery Level (5 Bars), Speed, Avg Speed, Max Speed, Odometer, Trip, Trip Time, Amp Output Chart, Assist Level (0-5) - DRIVE MODE
Torque Sensing Pedal Assist (Torque Sensing Bottom Bracket, Left and Right Side) - TOP SPEED
50kph on a flat road, pedal-assisted - MADE BY VINTAGE ELECTRIC USA
