E-BIKE SPECIFIC SPECIFICATIONS
MOTOR - Shimano EP8, DU-EP8, 250W, 85Nm
BATTERY - Shimano BT-E8036 630 Wh, 36 V
DISPLAY AND SWITCH - Shimano EM800
SPECIFICATIONS
- FRAME
6061-T6 Monocoque UK Formed Custom Aluminium Tubing. travel: 160mm, 12x148mm dropouts - FORK
RockShox Zeb Ultimate 170mm 29" - REAR SHOCK
RockShox Super Deluxe Ultimate 230x65 - FRONT TYRE
Maxxis Minion DHF 2.5 3c EXO+ - REAR TYRE
Maxxis Minion DHR II 2.4 3c EXO+ 27.5 - REAR DREAILLEUR
SRAM GX Eagle 12spd - CASSETTE
SRAM XG 1275 10-52t Eagle - CHAIN
SRAM NX Eagle - CRANK
Shimano E8050 165mm
- CHAIN RING
Narrow Wide, 34 T - SHIFTER
SRAM GX Eagle - Single Click - SEATPOST
SDG Tellis 150mm - WHEELSET
E13 TRS 30mm (Grey) + Hope Pro 4 (Black) 27.5/29 - BRAKES
Shimano SLX Trail 203/203 - HANDLEBAR
Burgtec RideWide Enduro 800mm - SADDLE
SDG Strange Bel Air III - STEM
Burgtec MK3 Enduro CNC Black 35mm - GRIPS
Strange Grappler Lock-On
The Phase MX is our mixed size wheelset E.P.O model. With a 29” front wheel paired with a 27.5 rear wheel and 170 mm front and 165mm rear suspension travel, We think this makes the Phase MX a strong contender to be our most versatile E.P.O. model to date. The mixed 29/27.5 wheel set has settled in well with its combination of fast rolling, bump absorbing big front wheel combined with the agility of the 27.5 rear makes it a winning combination. It's not just on World Cup DH or EWS bikes, it works well for riders of all disciplines and we now have popular MX models from hardtail through to the Phase MX: Our brand new, big travel eMTB.
The new Phase MX features a brand new and improved frame and the Shimano EP8 drive system with the 630Wh integrated battery, offering 25% more capacity for even longer rides.
THE RIDE
The confident geometry, with its agility and stability is better than ever, and for the 2022 line up, we’ve upped the travel both front and rear, while keeping that low CofG we are famed for. With a power assisted bike long travel makes sense, climbing with extra watts in your legs or descending at speed, this bike needs to take the hits in its speedy stride.
The 2022 Phase MX geometry solidly ticks its performance orientated boxes with a 64° head angle, 76° seat angle, balanced reach (483mm Size: Large), With 165mm of travel from the 230x65 metric shock and a reduced offset 170mm travel fork.
