Bosch Performance Line smart system drive with 75 Nm
Integrated Bosch PowerTube battery with choice of 625 or 500 Watt hour capacity
Range up to 120 km*
Shimano MT200 hydraulic disk brakes
KEY FEATURES
DRIVE UNIT Bosch Performance Line Smart System, 36 V / 250 W / 75 Nm
BATTERY Bosch PowerTube Li-Ion 36 V (500 Wh)
DISPLAY Bosch Intuvia 100, with LED Remote
RANGE up to 120km ,depending on terrain and riders weight
USAGE City, commuting, rail trails, e- trekking
SPECIFICATIONS
- SHIFTING SYSTEM
Shimano Alivio, 9-speed - SHIFTER
Shimano Alivio - CRANKSET
aluminium - GEAR RATIO
- front: 42, rear: 11-36
- DRIVETRAIN
KMC X9 - BRAKES
Shimano MT200, hydraulic disc brake - BRAKE ROTORS
front: 180 mm, rear: 180 mm - FRONT-LIGHT
Herrmans H-Black MR4, LED - REAR-LIGHT
Herrmans H-Trace, LED - FRAME
Integrale 3|23 - FORK
SR Suntour XCM ATB, blockierbar - TRAVEL
80 mm
- STEM
Aluminium, adjustable - HANDLEBAR
Sport riser, Aluminium, Tour, Aluminium - GRIPS
Ergon GP10, Ergon GC10 - SADDLE
Selle Royal Vivo - SEATPOST
Concept EX, aluminium - PEDALS
MTB, with reflector - RIMS
Hohlkammer, geöst, Aluminium, 25 mm - HUBS
front: Shimano TX505, QR
rear: Shimano TX505, QR - TYRES
Schwalbe Smart Sam, 54-584 (27,5'') - FENDER
plastic, with edge protector - CARRIER
Tour, aluminium - KICKSTAND
rear stand, adjustable - PERMISSIBLE TOTAL WEIGHT
130 kg
