MORE DYNAMIC AND RANGE, BUT LESS WEIGHT
Shimano's EP8 e-drive offers dynamic power and a lightweight system that supports the JAM² 7.8's agile geometry. Furthermore, our specially developed, integrated, yet removable battery supports your super long rides with 720 Wh. Additionally, a USB C port on the top tube gives you the opportunity to charge your devices.
OPTIMIZED KINEMATICS FOR STRONG PROGRESSION
Shimano's EP8 e-drive offers dynamic power and a lightweight system that supports the JAM² 7.8's agile geometry. Furthermore, our specially developed, integrated, yet removable battery supports your super long rides with 720 Wh. Additionally, a USB C port on the top tube gives you the opportunity to charge your devices.
MORE FUN ON THE TRAILS
Riding performance first. The JAM² 7.8 will make your ride better – every time. An agile, nimble geometry in a slim, compact design will push you over all kind of trails whether technical or flow. The FLIP CHIP at your JAM² 7.8's linkage can be used to adjust your geometry to an even more aggressive riding style. The small adjustment of the head angle from 65,5° to 65° changes your whole set-up goal making it even more downhill-oriented. Additionally, the specially developed C.I.S. (Cockpit Integration Solution) design ensures a clean cockpit and constantly seamless shifting and braking. All cables run from the handlebar into the stem and through the headset into the frame. On top, all your essentials fit in the tool bag between top and down tube.
KEY FEATURES
DRIVE UNIT Shimano Steps EP8, 36V / 250 W / 85 Nm
BATTERY 720 Wh
DISPLAY Shimano Steps E5003
SPECIFICATIONS
- FRAME
7005 hydroformed aluminium, 3D forging, 150 mm F.O.L.D. GEN2 kinematics, 148x12 mm thru axle, internal cable routing, USB-C port, post mount 203 mm - FRAME MATERIAL
Aluminium - FORK
Rock Shox 35 Gold RL 29 Boost, 110x15mm, 44mm rake, 150mm travel - TRAVEL FORK
150 mm - SHOCK
Rock Shox Deluxe Select, 210/55 mm, hardware: 25.0 x 8.0 mm, no Bushing - SHIFTER
Shimano SLX M7100, 12-speed - REAR DERAILLEUR
Shimano SLX M7100, 12-speed - SPROCKET
Shimano SLX M7100, 12-speed - CHAIN
Shimano CN-LG50 - CRANKSET
Samox EC40 ISIS - BOTTOM BRACKET
Integrated in Drive Unit - TRANSMISSION OF DRIVE
Front: 36T, Rear: 10-51T - HANDLEBAR
Aluminium, 800 mm, rise: 30 mm, backsweep: 9°
- STEM FOCUS C.I.S.
integrated, 50 mm, 0°, 35 mm, aluminium - HEADSET
ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated, 1.5/1.8" angle headset - SADDLE
FOCUS Race SL - SEATPOST
FOCUS Post Moderne dropper post PM-214, 34.9 mm - BRAKES
Shimano MT520, hydraulic disc brake - BRAKE LEVER
Shimano MT520n - BRAKE
Disc - RIMS
RaceFace AR30 Offset - REAR HUB
Shimano MT410, 12x148 mm - FRONT HUB
Shimano MT410, 12x148 mm - TYRES
Maxxis Minion DHF, EXO, 63-622 - GEARS
12 - BIKE WEIGHT
INCL. BATTERY IN KG 25 kg - SIZE
S, M, L, XL
